Strobe Panel LEDs
LED Type: 1.5W RGB 3in1 LEDs
LED Count: 504 LED
Colors: RGB
LED Segments: 14 (2 x 7)

Strobe Tube LEDs
LED Type: 5W 6500K LEDs
LED Count: 280
LED Colors: Cool-White
LED Segments: 28(2x14)

Movement
Resolution: 8-16 Bit
Tilt (Degrees): 185°

Control
Control Modes: 8CH / 18CH / 25CH / 95CH / C 8CH /C 11CH / C 13CH / C 24CH / C 30 CH / C 47CH / C 68CH/C 74CH / C 97CH
Display: Illuminated graphic LCD Touch Screen
Protocol: USITT DMX-512, RDM, Art-Net, sACN
RDM: Bidirectional communication
Wireless DMX: 2.4 GHz W-DMX™ (optional)
Cooling: Temperature controlled, overheating protection

Effects
Dimmer: 0-100% electronic Shutter: electronic, max. 20 Hz Internal Effects: LED Macro Effects

Connectors
Signal connection: Seetronic IP65 XLR 5-Pin or 3-Pin In/Out Power Input: Seetronic PowerCON TRUE1 In
Art-Net: RJ45 In/Out

Operating Conditions
Mains voltage: 100-240V AC / 50-60Hz Power: 1800W
Maximum ambient temperature: -30°C / 86°F, 50°C / 122°F Operating Position: any

Mounting Options
Hanging: Omega-Bracket (Support arm side hanging)
Safety wire attachment: foldout eyelets
Folding clamps (optional)

Shipping
Single fixture: cardboard
Tourpack: 4-way Flight Case

Housing Colors
Standard colors: black

Dimensions
Length: 482 mm / 18.9 in
Width: 178 mm / 9.0 in
Height (head horizontal): 243 mm / 9.5 in

Weight
N.W: 13.0 kg     G.W: 16.0 kg

Size
56x43x25cm
